Part Number: 30255 R3
Revised: 30/6/15
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
GRAIN AUGERS
WR 60/80/100 X 26’ - 71’ EMD MODEL
ASSEMBLY & OPERATION MANUAL
ORIGINAL INSTRUCTIONS
WR EMD Augers covered in this manual:
60-26, 60-31, 60-36, 60-41, 60-51, 60-61
80-26, 80-31, 80-36, 80-41, 80-46, 80-51, 80-56, 80-61, 80-71
10-31, 10-41, 10-51, 10-61, 10-71

Table of Contents

Questions and Answers

  • D
    David PattonAug 9, 2025
    Why is there excessive noise or vibration in my Westfield 10-31 Farm Equipment?
    • J
      Justin BrownAug 9, 2025
      Excessive noise or vibration in your Westfield Farm Equipment can stem from various issues. It could be due to chatter from wooden bearings; in this case, try spraying penetrating lubricant between the shaft and bearing surface, as bearings will break in over time. Incorrectly adjusted truss cables can also cause this problem; support the end of the auger and adjust the cables so the auger is flat or curves slightly upwards. Other potential causes include flighting peeled back due to plugging (inspect the spout end and replace flight sections if necessary), inadequate lubrication of the top drive (fill with grease, not oil), bent flighting sections (straighten or replace them), or an obstruction in the tube (inspect for cloth, trash, or oily crop buildup).
  • C
    Christopher TownsendAug 17, 2025
    What to do if drive belts are jumping off pulleys on my Westfield 10-31?
    • B
      Brian KimAug 17, 2025
      Drive belts jumping off pulleys in your Westfield Farm Equipment can be caused by several factors. First, ensure that the motor is correctly aligned so that the drive and driven pulleys are properly aligned. Mismatched belts can also be a culprit; check the assembly section of your manual for the correct belt sizes and replace belts in pairs. Inadequate belt tension can also cause this issue; maintain the correct tension as specified in the assembly section. Finally, using a lower horsepower motor than recommended can lead to belts jumping off; consult your manual for the recommended motor sizes.
  • C
    Christopher HowardSep 1, 2025
    How to prevent premature wear on auger tubes of Westfield 10-31 Farm Equipment?
    • S
      Samantha BartonSep 1, 2025
      Premature wear on auger tubes in Westfield Farm Equipment can occur if the auger is run at low capacity or empty for an extended period, which frequently happens on farms using grain wagons. To prevent this, avoid leaving the auger unattended when filling bins. Depending on the application, a belt conveyor may be a more suitable option. Additionally, allowing the flighting to wear beyond the normal point of replacement can contribute to premature wear. When the flighting becomes razor-thin at the intake, replacement is critical because the double thickness at welded lap joints creates high spots that can accelerate spot tube wear.
  • A
    Alyssa WebsterNov 22, 2025
    Why do shear bolts fail repeatedly on my Westfield 10-31 Farm Equipment?
    • Y
      Yolanda FloresNov 23, 2025
      Repeated shear bolt failures in your Westfield Farm Equipment can be attributed to several causes. Ensure you are using the correct shear bolt type, as Westfield shear bolts are specifically designed for driveline protection; replace with the correct part number if needed. A shear bolt hole worn out-of-round can also cause this issue; frequent use of the incorrect shear bolt size can wear the mounting hole, creating a “scissor effect,” which may require replacement of the affected parts. Additionally, if corn spreaders in the bin cannot keep up with the auger output, slow down the auger or remove the corn spreaders. Flighting peeled back due to plugging, often when the bin has overfilled or corn spreaders restrict the end of discharge, can also cause shear bolt failures; inspect the flight...
