Part Number: 30797 R5
Revised: 1/6/2017
Read this manual before using product. Failure
to follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
GRAIN AUGERS
MKX130-84/94/114
ASSEMBLY & OPERATION
ORIGINAL INSTRUCTIONS

Table of Contents

Questions and Answers

  • B
    bpenaAug 1, 2025
    Why is my Westfield MKX130 auger not turning?
    • T
      Tom FloresAug 1, 2025
      The auger might not be turning due to several reasons: it could be plugged or obstructed, in which case you should identify and remove the obstruction. Alternatively, a bearing or the gearbox may have seized, requiring you to identify and replace the bearing, or fix/replace the gearbox. A chain could be broken, requiring repair or replacement. Another possibility is that the gearbox coupler bolt or the PTO shear bolt is broken or missing, and you'll need to replace the bolt.
  • A
    Amanda ReyesAug 5, 2025
    What to do if my Westfield Farm Equipment auger is noisy?
    • M
      matthew65Aug 5, 2025
      If your Westfield Farm Equipment auger is making unusual noise, it could be due to several factors. There might be an obstruction in the auger, which requires identification and removal. Check if the flighting shaft bolts are loose or damaged, and tighten or replace them as needed. The auger shaft could be bent or the flighting damaged, necessitating repair or replacement of the shaft or flighting. A worn bearing or low gear oil level in the gearbox can also cause noise; repair or replace the bearing, or inspect the gearbox for damage and add oil if no damage is found. Lastly, a misaligned tube could be the culprit, requiring adjustment of the truss cables.
  • W
    williamsjosephAug 9, 2025
    Why Westfield MKX130 Farm Equipment auger will not raise or lower?
    • G
      Garrett GeorgeAug 9, 2025
      If your Westfield Farm Equipment auger isn't raising or lowering, check for a closed hydraulic valve and open it. Inadequate hydraulic pressure could be the issue; adjust the pressure or use an alternate hydraulic supply. A damaged cylinder, missing or broken cylinder pin, or a hydraulic system leak could also be the cause, requiring you to fix or replace the cylinder, replace the cylinder pin, or identify and repair the leak. Finally, an obstruction to the auger's movement could be the problem; identify and clear any obstructions.
  • B
    Brian WilliamsonAug 13, 2025
    What to do if Westfield Farm Equipment auger will not stay in elevated position?
    • S
      Sophia DrakeAug 13, 2025
      If your Westfield Farm Equipment auger isn't staying in the elevated position, it could be due to a leak in the auger's hydraulic cylinder or fittings. Identify and repair the leak. Another potential cause is a leak in the tractor hydraulics; close the hydraulic valve to isolate the cylinder from the tractor hydraulics.
  • U
    uhernandezAug 18, 2025
    Why is the material augering rate low on my Westfield MKX130 Farm Equipment?
    • D
      Donald MurphyAug 18, 2025
      A low material augering rate in your Westfield Farm Equipment can stem from several issues. The tractor PTO speed might be too slow, so increase the engine rpm. Check for inadequate material flow from the truck or hopper and increase the flow. A restricted flow into the auger hopper due to obstructions on the grating can also cause this; clear any obstructions. Note that unloading rates are for dry grain, so if the material is too wet or heavy, this could be the reason. Lastly, worn flighting can reduce the rate; repair or replace as required.
  • K
    Karen EdwardsAug 22, 2025
    What to do if upper auger sections will not turn in Westfield MKX130 Farm Equipment?
    • S
      stanleyrebeccaAug 22, 2025
      If the upper auger sections of your Westfield Farm Equipment are not turning, the coupler bolt below the non-rotating section might be broken or missing. Replace the bolt.
  • A
    arodriguezAug 27, 2025
    Why is the tube misaligned on my Westfield Farm Equipment?
    • R
      Richard SmithAug 27, 2025
      If the tube on your Westfield Farm Equipment is misaligned, it might be due to loose truss cables. You should tighten the cables as required.

Summary

Introduction

Overview

General overview of auger features and optional kits.

Auger Power Source

Explains PTO options for powering the auger.

Grain Transfer Boot

Details the function and components of the grain transfer boot.

Grain Hopper

Describes the low-profile grain hopper and its operation.

Auger Tube Hydraulic Lift

Explains the hydraulic system for raising and lowering the auger tube.

Safety

General Safety Information

Introduces safety alerts, signal words, and their importance.

Assembly Safety

Crucial safety guidelines for the assembly process.

Operation Safety

Essential safety practices during auger operation.

PTO Safety

Safety precautions related to the Power Take-Off (PTO) driveline.

Hydraulic Safety

Safety measures for the hydraulic system and its components.

Transport & Placement Safety

Advises on safe practices during transport and positioning.

Maintenance Safety

Highlights safety procedures before and during maintenance.

Safety Decals

Explains the importance and location of safety decals.

Assembly

General Assembly

Guidelines and tool requirements for overall assembly.

Assemble the Auger Tube

Steps for assembling the main auger tube sections.

Install Hydraulic Lift Cylinders

Instructions for installing hydraulic lift cylinders.

Connect Auger Tubes

Steps for bolting auger tube sections together.

Install the Boot on the Auger Tube

Procedures for attaching the boot assembly.

Connect Hydraulic Hoses and Ball Valve

Guides for connecting hydraulic lines and valve.

Connect the PTO Driveline

Steps for attaching PTO driveline.

Auger-to-Tractor Hookup

Critical steps for hitching auger to tractor.

Transport

Transport Procedure

Step-by-step instructions for safely transporting the auger.

Placement

Placement Procedure

Steps for safely positioning the auger for operation.

Positioning Tractor for Right-angle Drive Operation

How to position the tractor for right-angle PTO drive.

Lowering the Auger

Procedures for safely lowering the auger.

Operation

Operator Controls

Identifies key controls for auger operation.

Pre-Operation

Checklist and checks before starting auger operation.

Operating Procedures

Detailed steps for operating the auger.

Initial Start-Up

Guide for first-time start-up and break-in.

Normal Shutdown

Steps for safely shutting down the auger.

Reverser Operation

Instructions for using the reverser function.

Maintenance and Storage

Maintenance Intervals

Table outlining maintenance tasks and their frequency.

Fluids and Lubricants

Specifies required gear oil and grease types.

Maintenance Procedures

Detailed procedures for various maintenance tasks.

Upper;Lower Gearbox Oil Level

How to check and maintain gearbox oil levels.

Storage

Procedures for preparing the auger for storage.

Appendix

Specifications

Technical specifications for auger models.

Bolt Torque Values

Torque values for various bolts used in assembly.

WARRANTY
