Westfield 80-31 User Manual

64 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

Part Number: 30255 R3

Revised: 30/6/15

Read this manual before using product. Failure to

follow instructions and safety precautions can

result in serious injury, death, or property

damage. Keep manual for future reference.

GRAIN AUGERS

WR 60/80/100 X 26’ - 71’ EMD MODEL

ASSEMBLY & OPERATION MANUAL

ORIGINAL INSTRUCTIONS

WR EMD Augers covered in this manual:

60-26, 60-31, 60-36, 60-41, 60-51, 60-61

80-26, 80-31, 80-36, 80-41, 80-46, 80-51, 80-56, 80-61, 80-71

10-31, 10-41, 10-51, 10-61, 10-71

Table of Contents

Other manuals for Westfield 80-31

Operating Manual62 pages

Questions and Answers:

J
Joseph OliverAug 20, 2025
Why is there excessive noise or vibration in my Westfield 80-31 Farm Equipment?
- P
  pamelahillAug 20, 2025
  Excessive noise or vibration in your Westfield Farm Equipment can stem from various issues. It could be due to chatter from wooden bearings; in this case, try spraying penetrating lubricant between the shaft and bearing surface, as bearings will break in over time. Incorrectly adjusted truss cables can also cause this problem; support the end of the auger and adjust the cables so the auger is flat or curves slightly upwards. Other potential causes include flighting peeled back due to plugging (inspect the spout end and replace flight sections if necessary), inadequate lubrication of the top drive (fill with grease, not oil), bent flighting sections (straighten or replace them), or an obstruction in the tube (inspect for cloth, trash, or oily crop buildup).
J
James LyonsAug 22, 2025
What to do if drive belts are jumping off pulleys on my Westfield 80-31 Farm Equipment?
- S
  Sydney HarrisAug 22, 2025
  Drive belts jumping off pulleys in your Westfield Farm Equipment can be caused by several factors. First, ensure that the motor is correctly aligned so that the drive and driven pulleys are properly aligned. Mismatched belts can also be a culprit; check the assembly section of your manual for the correct belt sizes and replace belts in pairs. Inadequate belt tension can also cause this issue; maintain the correct tension as specified in the assembly section. Finally, using a lower horsepower motor than recommended can lead to belts jumping off; consult your manual for the recommended motor sizes.
J
James GarciaAug 26, 2025
How to prevent premature wear on auger tubes of Westfield 80-31 Farm Equipment?
- R
  Rebecca GarrettAug 26, 2025
  Premature wear on auger tubes in Westfield Farm Equipment can occur if the auger is run at low capacity or empty for an extended period, which frequently happens on farms using grain wagons. To prevent this, avoid leaving the auger unattended when filling bins. Depending on the application, a belt conveyor may be a more suitable option. Additionally, allowing the flighting to wear beyond the normal point of replacement can contribute to premature wear. When the flighting becomes razor-thin at the intake, replacement is critical because the double thickness at welded lap joints creates high spots that can accelerate spot tube wear.
M
Michael WalkerAug 27, 2025
Why is there poor product flow in my Westfield 80-31?
- J
  Jessica HicksAug 27, 2025
  Poor product flow can occur for several reasons. The input speed may be too slow, so try increasing the engine rpm. There might be inadequate material flow from the truck or hopper, so increase the flow of material. A restricted flow into the hopper can also be the cause, in this case, clear the grating of obstructions. If the material is too wet or heavy, remember that unloading rates are for dry grain. Worn flighting or a slipping belt can also lead to this issue; repair or replace the flighting as required, and identify, adjust or replace the slipping belt.
B
Brian FryeAug 29, 2025
What to do if my Westfield Farm Equipment machine operates slowly?
- V
  vwebbAug 29, 2025
  If your machine operates slowly, several factors could be responsible. The oil might be hot; check the oil level and add oil if needed. The power source may not be producing enough oil volume or pressure; speed up the engine to produce more flow/pressure, or consider that the power unit may lack sufficient capacity. If equipped, a plugged filter could be the issue, so change the filter. Additionally, the cushion block might need adjusting; adjust the valve on the cushion block by turning it inward 1/8 of a turn at a time, referring to the Ram and Travel Speed guidelines.
D
Daniel WoodardAug 31, 2025
Why is my Westfield Farm Equipment making excessive noise or vibration?
- M
  Michael FigueroaAug 31, 2025
  Excessive noise or vibration can be attributed to a few things. If you hear chatter from wooden bearings, spray penetrating lubricant between the shaft and bearing surface, allowing time for the bearings to break in. If equipped, incorrectly adjusted truss cables can cause this; support the end of the auger and adjust the cables so the auger is flat or curves slightly upwards. Also, inspect the spout end of the auger for flighting condition, as flighting peeled back due to plugging can also be the cause; remove and replace flighting sections as necessary.
P
pameladonovanSep 2, 2025
What to do if the flighting does not turn on my Westfield 80-31 Farm Equipment?
- F
  Fernando LoganSep 2, 2025
  If the flighting isn't turning, it could be due to several reasons. The auger flighting might be plugged or obstructed; identify and remove any obstructions. A bearing could be seized; identify and replace it. A chain might be broken; identify the chain and repair or replace it. In some cases, the upper drive chain is broken, you should repair or replace it. The gearbox might be seized, you should fix or replace it. Alternatively, the gearbox coupler bolt could be broken or missing; replace the bolt.
E
Emily RiosSep 4, 2025
How to fix drive belts jumping off pulleys on my Westfield Farm Equipment?
- K
  Kristine SmithSep 4, 2025
  If the drive belts are jumping off the pulleys, first ensure that the drive and driven pulleys are correctly aligned, as a misaligned motor can cause this. Also, check the Specifications section for correct belt sizes and only replace belts in pairs if they are mismatched. Inadequate belt tension can also be the culprit, so adjust the tension accordingly. Finally, verify that you are not using a lower horsepower motor than recommended; see the Specifications for recommended motor sizes.
P
Peggy AyersSep 6, 2025
What to do if the auger will not raise or lower on my Westfield Farm Equipment?
- R
  richard71Sep 6, 2025
  If the auger won't raise or lower, it might already be at its maximum or minimum height; if at maximum height, lower the auger. There could also be an obstruction in the slide; clear any obstructions. A faulty cable could be the cause, so replace the cable. In the case of a faulty winch, consult your local dealer.
S
Sally McleanSep 7, 2025
Why is my Westfield 80-31 Farm Equipment hydraulic winch not raising the auger?
- D
  Duane DiazSep 8, 2025
  If the hydraulic winch isn't raising the auger, the relief valve pressure might be set too low; adjust the relief valve pressure, referring to the Hydraulic Pressure Adjustment guidelines. The oil level could also be too low; check the oil level and replenish if necessary. In some cases, a worn-out pump may be the cause, so replace the pump.
