30 | Westinghouse Portable Power
WGen3600v ENGINE VIEW
No. Part. Description Qty
1 180556 Ball Bearing 2
2 180541 Oil Seal 2
3 180543 Drain Plug 2
4 180544 Drain Plug Seal 2
5 180546 Crankcase Cover 1
6 170502 Hose Clip 1
7 180548 Cylinder Head
Assy
1
7.1 180526 Spark Plug 1
7.2 180555 Valve Cover
Gasket
1
7.3 180554 Valve Cover 1
7.4 140515 M6 Stud 2
7.5 140516 Gasket 1
7.6 180571 M10X80 Stud 2
8 140512 Carburetor Assy 1
9 140518 Fuel Hose 1
10 140508 Hose Clamp 1
11 180549 Govenor Arm 1
12 100548 M6 Nut 3
13 180545 Gasket 1
14 110503 M8X30 6
15 180547 Cylinder Head
Gasket
1
16 180533 Heat Shield 1
17 120505 M6X12 13
18 180566 Dust Plate 1
19 180567 M6X20 1
20 180540 Flywheel Assy 1
21 180539 Engine Cooling
Fan
1
22 180538 Starter Cup 1
23 180537 Crankshaft Nut 1
24 180542 Ignition Coil Assy 1
25 100518 M6X25 2
26 140514 Spacer 1
27 140513 Gasket 1
28 140517 Gasket 1
29 180570 Govenor Linkage 1
30 180551 Throttle Return
Spring
1
31 170501 Recoil Assy 1
32 180552 Govenor Bracket 1
33 160501 Air Cleaner Assy 1
34 180559 Vent 1
35 140506 Fitting 1
36 180550 Govenor Spring 1
37 180509 Amplier 1
38 180557 Dipstick 1
