SAFETY
USER MANUAL
WGen9500DF
Dual Fuel Portable Generator
Gasoline: 9500 Running Watts | 12500 Peak Watts
Propane: 8500 Running Watts | 11200 Peak Watts
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have questions or need assistance, please call customer
service at 855-944-3571.

Table of Contents

Questions and Answers

  • H
    Heather ColemanSep 3, 2025
    Why is there frost on the propane tank of my Westinghouse WGen9500DF?
    • D
      Dale NelsonSep 4, 2025
      Frost on the propane tank or regulator of your Westinghouse Portable Generator can occur if the tank temperature drops below the dew point, especially in humid conditions. If the propane fuel handling equipment is functioning normally, no correction is needed. If you suspect your propane fuel tank is not equipped with an Over­ filling Prevention Device (OPD), discontinue operation immediately and replace the propane fuel tank with a propane tank equipped with an OPD. If you suspect your propane fuel tank has been overfilled, discontinue operation immediately and return the propane fuel tank to the place of purchase or refilling.
  • S
    Sarah BrockSep 18, 2025
    What to do if there is no power at AC receptacles on my Westinghouse WGen9500DF?
    • J
      Jessica SaundersSep 18, 2025
      If there is no power at the AC receptacles of your Westinghouse Portable Generator, check the AC loads and reset the circuit breaker(s). Also, a faulty power tool or appliance can be the reason, so replace or repair the tool or appliance, then stop and restart the engine.
  • I
    Ian WeberSep 16, 2025
    What to do if Westinghouse Portable Generator runs rough?
    • A
      Amanda PopeSep 16, 2025
      If your Westinghouse Portable Generator runs rough or bogs when a load is applied, try cleaning the air filter. Also, the generator might be overloaded, so unplug some devices. If you're using a faulty power tool or appliance, replace or repair it, then stop and restart the engine.
  • D
    Donald AyalaSep 14, 2025
    What causes poor performance or engine stalling on Propane in my Westinghouse WGen9500DF Portable Generator?
    • D
      danny06Sep 14, 2025
      Poor performance or engine stalling on propane can be caused by a kinked or crushed propane fuel line (inspect and remove any obstructions), a fuel selector valve not properly positioned (rotate the valve fully until it aligns with the desired fuel), or gasoline not purged from the carburetor before switching to propane (close the propane tank valve, switch to gas, run the engine until the gasoline is consumed, then begin the propane start-up procedure).
  • D
    drussellSep 12, 2025
    Why is there frost on the propane tank or regulator of my Westinghouse WGen9500DF?
    • C
      cookjonathanSep 12, 2025
      Frost on the propane tank or regulator can occur if the tank temperature drops below the dew point, especially in humid conditions; if all equipment is functioning normally, no action is needed. If you suspect your propane fuel tank is not equipped with an Overfilling Prevention Device (OPD), discontinue operation immediately and replace the propane fuel tank with a propane tank equipped with a an OPD. Also, if you suspect your propane fuel tank has been overfilled, discontinue operation immediately and return it to the place of purchase or refilling.
  • S
    Sarah CortezSep 12, 2025
    How to fix rough running or bogging of Westinghouse WGen9500DF Portable Generator engine when load applied?
    • R
      ronaldhernandezSep 12, 2025
      If your Westinghouse Portable Generator runs rough or bogs when a load is applied, the likely causes are a dirty air filter (clean it), the generator being overloaded (unplug some devices), or a faulty power tool or appliance (replace or repair the tool or appliance, then stop and restart the engine).
  • E
    Emily DavisSep 9, 2025
    What to do if my Westinghouse Portable Generator engine lacks power?
    • A
      Alicia VasquezSep 9, 2025
      If your Westinghouse Portable Generator engine lacks power, it could be because the air filter is restricted (clean or replace it) or due to bad fuel (drain the fuel tank and refuel with fresh gasoline).
  • M
    Matthew MartinezSep 7, 2025
    Why is there no power at the AC receptacles of my Westinghouse WGen9500DF Portable Generator?
    • D
      Devin CastilloSep 7, 2025
      If there's no power at the AC receptacles, it could be due to several reasons. The OUTPUT READY LED might be OFF and the OVERLOAD LED might be ON (check the AC load, stop and restart the engine), AC circuit breaker/s might be tripped (check AC loads and reset the circuit breaker/s), or a faulty power tool or appliance might be connected (replace or repair the tool/appliance, then stop and restart the engine). Also check the air inlet, stop and restart the engine.
  • S
    Shannon MoodySep 5, 2025
    What to do if my Westinghouse WGen9500DF starts then shuts down?
    • M
      Martha CarrilloSep 5, 2025
      If your Westinghouse Portable Generator starts and then shuts down, possible causes include: being out of fuel (refuel), incorrect engine oil level (check the level), a dirty air filter (clean it), or contaminated fuel (drain the tank and refuel with fresh gasoline).
  • C
    Carlos HarrisAug 20, 2025
    Why won't my Westinghouse Portable Generator start?
    • J
      John WeberAug 21, 2025
      There are several reasons why your Westinghouse Portable Generator might not start. It could be due to the battery switch being in the OFF position (turn it to ON), running out of fuel (refuel), bad fuel (drain and refuel with fresh gasoline), a dirty air filter (clean it), low engine oil level (add oil after turning the battery switch OFF), a wet spark plug (wait five minutes, turn the battery switch OFF, and pull the recoil handle rapidly, remove and dry spark plug if needed), a faulty spark plug (gap or replace it), or a drained battery (use the recoil handle to start). Also check the choke, manually set the choke if it is partially open or closed due to weak or disconnected battery.

Summary

Safety

Safety Definitions

Safety Symbols

Safety Instructions

Essential guidelines for safe operation, including carbon monoxide poisoning prevention.

Hazard Warnings

Highlights critical hazards like electrocution and fire, and advises on electrical system connections.

General Safety Precautions

Fuel Safety

Liquid Petroleum Gas (LPG;Propane) Safety

Features

Generator Components

Control Panel Components

Details each control, indicator, and receptacle on the generator's control panel.

Assembly

Install Feet and Wheels

Initial Oil Fill

Crucial instructions for adding engine oil before the first startup to prevent damage.

Fuel Requirements

Details the correct type, octane, and ethanol content of gasoline to use.

Filling the Fuel Tank

Connect a LPG;Propane Tank

Connect the Battery

Operation

Generator Location

Safety guidelines for placing the generator outdoors in a well-ventilated area.

Grounding

Explains the importance of grounding and how to do it properly.

Remote Start

Fuel Selector Switch

Before Starting the Generator

Starting the Engine: Gasoline

Step-by-step process for starting the generator using gasoline.

Starting the Engine: Propane

Step-by-step process for starting the generator using propane.

Switching Fuel Sources

Stopping the Engine

AC Circuit Breakers

Generator Capacity

Guidance on calculating power needs and understanding generator output limits.

Power Management

Extension Cords

Transporting

Maintenance

Maintenance Schedule

Lists recommended maintenance tasks based on operating hours or time intervals.

Air Filter Maintenance

Engine Oil Level Check

Procedure for checking the engine oil level before each use.

Engine Oil Change

Step-by-step guide for changing the engine oil.

Spark Plug Maintenance

Battery Maintenance

Battery Replacement

Storage

Long Term Storage

Valve Clearance

Troubleshooting

Engine Will Not Start

Common causes and corrections for the generator failing to start.

Engine Starts, Then Shuts Down

Solutions for when the engine starts but then stops unexpectedly.

Engine Lacks Power

Diagnosis and remedies for reduced engine power or bogging.

No Power at AC Receptacles

Troubleshooting steps when the generator outlets are not providing power.

Propane Fuel Smell

Poor Performance or Engine Stalling on Propane

Exploded View

Exploded View A

Comprehensive parts list corresponding to the Exploded View A diagram.

Exploded View A Continued

Continuation of the parts listing for Exploded View A.

Exploded View B

Comprehensive parts list corresponding to the Exploded View B diagram.

Exploded View B Continued

Schematics

Schematics

Westinghouse WGen9500DF Specifications

General IconGeneral
Fuel Tank Capacity6.6 gallons
Noise Level74 dBA
Voltage120/240V
Frequency60 Hz
Wheel KitIncluded
Running Watts (Gasoline)9500W
Peak Watts (Gasoline)12500W
Running Watts (Propane)8500W
Peak Watts (Propane)11200W
Engine457cc
Run Time (Gasoline)12 hours
Start TypeElectric and Recoil
Fuel TypeGasoline, Propane
Dimensions27.2 x 26.1 x 26 inches
Warranty3 years limited
