14 REVERSING DOOR
In these examples the operation is changed from right
side hinging to left side hinging.
Precautions
• Turn off the appliance.
• Unplug the power cable.
• Remove all food from the appliance.
• Remove shelves and baskets.
• Do not lay the appliance down flat on its back as this
will impair its operation.
• When tilting the appliance to access the underside,
support it so that it will not fall to the floor.
Note: All parts removed must be retained to reinstall
door.
REVERSING THE DOOR OPENING DIRECTION
(WIM1000)
• Support the door from below and remove the two
screws (1) that secure the hinge (2) to the bottom
right side of the appliance. Stand the door to one
side carefully.
• Unscrew the left front leg (3) and transfer it to the
right side.
• Remove the metal hinging pin (6) and the spring (5)
beneath it from the hole in the top right hand corner
of the door.
• Insert the spring (5) first and then the pin (6) –
previously removed from the right hand side – into
the top left hole.
• Position the door on the cabinet with the pin (6)
protruding from the top left corner entering the
corresponding hole (arrowed in left hinging assembly
illustration) under the top frame of the cabinet.
• While holding the door in the closed position, secure
the hinge (2) – previously removed from the other
side – onto the bottom left corner, tightening the 2
screws (1) firmly.
Right sided hinging assembly
1
2
7
6
5
3
Left sided hinging assembly
1
3
5
6 7
2
