Westinghouse WSF6608 - Australian Standard AS;NZ 60335 2; Technical Specifications; Conformity with the Standards and Test Data

5
DESCRIPTION
12
DESCRIPTION OF YOUR APPLIANCE
TECHNICAL SPECIFICATIONS
Capacity ......................................... 15 place settings
Height .........................................................845 mm
Height (without worktop) ..............................820* mm
Width .........................................................596 mm
Depth .........................................................598 mm
Net Weight ..................................................... 56 kg
Electricity input ............................... 220-240 V, 50 Hz
Total Power .................................................2200 W
Heating Power ............................................. 2000 W
Pump Power ...................................................100W
Drain Pump Power ............................................30 W
Water supply pressure ... 0.03 MPa (0,3 bar) - 1 MPa (10 bar)
Water supply temperature... ...........................5 - 60°C
Current ........................................................... 10 A
1. Worktop
2. Upper basket with racks
3. Upper spray arm
4. Lower spray arm
5. Filters
6. Lower basket
7. Rating plate
8. Control panel
2
3
4
6
5
7
8
9
10
1
9. Detergent and rinse-aid dispenser
10. Upper cutlery basket
11. Turbo drying unit
12. Ceiling spray impeller
11
• Electrolux reserves the right to amend design and
technical specifications.
* with counterweight and insulation removed
