58
Machine control board, Software
704 67 020 00 _ 111
GF Robimat XL / XM
OPERATING INSTRUCTIONS
[P.LIST / READER]
[L1+L2 -> all] Both price lists are valid for card 1 and card 2.
[L1->R1/L2 ->R2] Price list 1 is valid for card 1, price list 2 is valid for card 2.
[MIXED PAYM.] Which price is to be used for [MIXED PAYM.] can be selected here.
[Cash price] The [PRICE CASH] entered in the [PROGRAMMING MODE] menu M1 is used.
[Cashless price] The price entered in the menu [PROGRAMMNG MODE] is used for the respective [PRICE
LIST 1] or [PRICE LIST 2].
[MDB-comp.mode]
[standard] This is the standard setting. Most credit systems work in this mode.
[b. practice] Additional information is transmitted in this mode. It is required mainly for future
applications. Some credit systems already work in this mode.
[REFUND FAILURE] How the vending machine is to react if an error occurs during product delivery is
programmed here.
[CLEAR CREDIT] This is the standard setting. The credit is deleted.
[USE AS CASH] The amount is topped up on a card or key when it is allowed to do so by the card reader
and [REVALUE] is set to [on]. If no card reader is connected, the amount is converted into
cash. The credit remains for the amount of time set under [CLEAR CREDIT] in sub-menu
[CREDIT SYSTEM].
[MDB ITEM
NUMBERS]
Denes how selection number data is transmitted in Vend Request and other MDB
commands.
[HEX VALUE] Standard setting
[BCD] Selection numbers are transmitted BCD-coded. Some card systems require this coding.
[CARD REMOVAL]
[before vend] The card can be removed before product delivery.
[after vend] The card can only be removed after product delivery.
[CASH SALE]
[MDB42] (default) The Cash Sale command operates in accordance with MDB 4.2 version.
MDB41 This Cash Sale command is used specically and requires special knowledge in MDB
programming.
[EVA/DTS SEL.No.] You can determine how the selection numbers are reported to MDB here and in EVA-DTS.
This setting has no eect on machines with selection numbers starting with 1.
[starts with 1] (default) The lowest selection number in the machine is 1.
[starts with 10] The number being transmitted, is the one shown as the selection number on the display.
[MDB CARD 2]
[on] Activate if a second card reader is connected.
[o] If no second card reader is connected.
