13 Test Running13 Test Running
Inspection before runningInspection before running
User ManualUser Manual User ManualUser Manual
For safe running, user should inspection the items show as following items
before power on.
For safe running, user should inspection the items show as following items
before power on.
Is the power of the soft starter match to that of the motor?
Does the insulation of the motor meet the requirement?
Is the wiring of power and motor line right?
Do all the nut screw tightly
Measure the input power (R\S\T) using multimeter, Check whether
there is short circuit.
Is the power of the soft starter match to that of the motor?
Does the insulation of the motor meet the requirement?
Is the wiring of power and motor line right?
Do all the nut screw tightly
Measure the input power (R\S\T) using multimeter, Check whether
there is short circuit.
Note:
1. There is linear power transformer between any two phases of power side.
Static resistance is about 300 .
2. There are fans between any two phases of load side. Static resistance is about
2k .
Note:
1. There is linear power transformer between any two phases of power side.
Static resistance is about 300 .
2. There are fans between any two phases of load side. Static resistance is about
2k .
If any fault is detected, responded fault code will show on the keyboard.
See Table 12-1, Please deal with them according to the corresponding
tips.
Warning: If the soft starter is power, don't open the shell cover to avoid
electric shock.
If any fault is detected, responded fault code will show on the keyboard.
See Table 12-1, Please deal with them according to the corresponding
tips.
Warning: If the soft starter is power, don't open the shell cover to avoid
electric shock.
Power on and trial runningPower on and trial running
When power is on, system enter Ready state, shows on the key-
board. It means everything is right. There are two lamp on the left of
the keyboard to indicate the starting mode ( Voltage Ramp or Current
Limit )
If the keyboard display correctly, press key to start the motor,
then the actual current displays on the keyboard.
At running state, press key to stop the motor, return to Ready state.
During trial running, if the terminal mode is selected, setting
parameter according to item in chapter 8, table 8-1.
If the motor is not connected to the output load terminal U V W of
the soft starter, step above can also be executed. It is useful to check
wiring of operate system, bypass contactor, all the lamp etc.
When power is on, system enter Ready state, shows on the key-
board. It means everything is right. There are two lamp on the left of
the keyboard to indicate the starting mode ( Voltage Ramp or Current
Limit )
If the keyboard display correctly, press key to start the motor,
then the actual current displays on the keyboard.
At running state, press key to stop the motor, return to Ready state.
During trial running, if the terminal mode is selected, setting
parameter according to item in chapter 8, table 8-1.
If the motor is not connected to the output load terminal U V W of
the soft starter, step above can also be executed. It is useful to check
wiring of operate system, bypass contactor, all the lamp etc.
Attention and SafeAttention and Safe
Warning: At the course of trial running, any abnormal phenomenon is
fond, such as: Abnormal sound, Smoking or abnormal smell,user should
cut off the power immediately.
If the motor is not connected to the output load terminal, power on,
voltage can be measured at the output power connections. This is
inductive voltage. This is normal phenomenon. This inductive voltage
disappears immediately after the motor is connected.
During trial running, if the starting effect is not ideal, user can modify
the parameter such as starting mode, current, voltage and time etc.
Warning: At the course of trial running, any abnormal phenomenon is
fond, such as: Abnormal sound, Smoking or abnormal smell,user should
cut off the power immediately.
If the motor is not connected to the output load terminal, power on,
voltage can be measured at the output power connections. This is
inductive voltage. This is normal phenomenon. This inductive voltage
disappears immediately after the motor is connected.
During trial running, if the starting effect is not ideal, user can modify
the parameter such as starting mode, current, voltage and time etc.
