5
UL-Listed Branch Circuit Breakers, Rated for 120V, Maximum 20A
e following breakers have been factory tested and approved for use as Branch breakers
in the WF-8930/50 Series Distribution Center:
Manufacturer Model/Cat. No./Type
Cutler Hammer Type BR and C, Type BRD, BD and A
omas Betts Type TB or TBBD
ITE/Siemens Type QP or QT
Square D Type HOM or HOMT
Murray Type MP-T or MH-T
General Electric Type THQL
When replacing any of the installed circuit breakers, the replacement should be of the same
manufacturer, type designation, and equal interrupting rating, not to exceed 30 A. e
“Short-Circuit-Current” rating for the breaker should be 10,000 Amps.
Breaker Filler Plates: Model #FP-01 or FP-01B (Black)
Figure 2
