5
1. TYPICAL INSTALLATION 11. INSTALLATION
2. SPECIFICATION 12. PLUMBING
3. CONTENTS AND LIST OF DIAGRAMS 13. INSTRUCTIONS FOR USE
4. PRINCIPLES OF OPERATION 14. MAINTENANCE
5. TO THE USER 15. HELPFUL HINTS
6. TO THE FITTER 16. TROUBLE SHOOTING
7. APPLICATION 17. WINTERISING
8. WARNINGS 18. PATENTS/ TRADEMARKS
9. PARTS LIST 19. WARRANTY STATEMENT
10. OPTIONAL EXTRAS 20. EU DECLARATION OF CONFORMITY,
APPROVALS
List of Diagrams:
Fig 1a Typical Installation as a High Capacity Grey Waste Pump for use with Gulley IC
Fig 1b Typical Installation as a High Capacity Grey Waste Pump for use with Two Way
Manifold IC
Fig 2 Typical Installation as a High Capacity Grey Waste Pump used with non-whale
accessories
Fig 3 Pump Orientation
Fig 4 Gulper® IC installation
Fig 5 Install P Clamp
Fig 6a Wiring Gulper® IC to Whale IC Accessories
Fig 6b Wiring Gulper® IC to Traditional Switch - non Whale IC Accessories
Fig 7 Connecting Switching Cable Through Bulkhead
Fig 8a STEP 1- Connect Deutsch Connectors
Fig 8b STEP 2 - Connect adaptor with 2 spades
Fig 9 Secure Pipework
IC - Intelligent control technology
At the heart of every Whale® IC product lies innovative electronic control circuitry built in. This
enables IC sensor accessories to communicate directly with IC pumps to control their performance.
These accessories send signals to built-in intelligent software which then control the pumps to react
as required.
Gulper® IC
The Gulper® IC fully automatic self-priming pump is designed to pump waste water from a shower
tray/galley sink, (either overboard or to a holding tank) or as a remote mounting bilge pump. Output
capacity depends on installation and operating conditions.
GREY WASTE APPLICATION - WITH WHALE® IC ACCESSORIES
When Gulper® IC is installed as a grey waste pump with Whale® IC Grey waste accessories,
electrical signals are sent from the Gulley IC or Two Way Manifold IC only when grey waste water
needs to be pumped out. (See Figs 1a and 1b)
GREY WASTE APPLICATION - WITH NON WHALE® IC ACCESSORIES
Gulper® IC may also be installed as a grey waste pump in conjunction with non whale accessories.
This allows the installer to fit low current controlled switching which prevents burn outs from high
current. (See Fig 2)
Read the following instructions carefully.
3. LIST OF CONTENTS AND LIST OF DIAGRAMS
4. PRINCIPLES OF OPERATION
5. TO THE USER
