Wharfedale Pro CPD Series User Manual

9
SPECIFICATION
Model Name CPD2600 CPD3600
Stereo Power Output
8 ohms*2 650W 870W
4 ohms*2 1
000W 1300W
Bridged Mono Output
8 ohms 1
940W 2590W
4 ohms 2600W 3600W
Input Sensitivity & impedance
Sensitivity 0dBu (0.775Vrms) 0dBu (0.775Vrms)
Balanced XLR input 20Kohms 20Kohms
Maximum Input Level 22dBu (9.7Vrms) 22dBu (9.7Vrms)
Voltage Gain 39dB 4
1dB
Slew Rate >40V / us >40V / us
Crosstalk <-70dB <-70dB
S/N >
100dB >100dB
Distortion (1W) <0.02% <0.02%
Frequency Response
+/-1dB @ 8 Ohmes 20Hz - 20KHz 20Hz - 20KHz
+/-3dB @ 8 Ohmes 20Hz - 30KHz 20Hz - 30KHz
Damping Factor >300 >300
Topology Class H Class H
Connectors
Signal Input and Output Female and Male XLR Jacks Female and Male XLR Jacks
Power Output SPEAKON Jacks SPEAKON Jacks
Controls
Front panel AC Switch, CH
1 and CH 2 Gain Knobs
Rear panel Parallel, Stereo & Bridge Mode Switch; Limiter Switch
Protections
Thermal protect, Over-current protect, Output DC protect, Output short protect,
Power on/off mute
Indictors Power, Protect, Signal, Limiter
Cooling Variable Speed Fan
AC Power Options
A
C110-120V~ 50/60Hz or AC100V~ 50/60Hz;
AC220-230V~ 50/60Hz or AC240V~ 50/60Hz
AC220-230V~ 50/60Hz or AC240V~ 50/60Hz
Dimensions 88*483*450mm 88*483*450mm
Carton Box
Weight (Net) 1
9kg 22kg
Weight (Gross) 22.5kg 25.5kg
