OPERATING MANUAL AND USER GUIDE
15
- Single 15˝, Two-way system.
- High Power Handling Capabilities up to 2000
Watts Peak.
- Integral pole mount adapter.
- 2 integral carry handles.
- 14 M-10 threaded inserts for suspension
applications (five on the top, three on the
bottom,
two on each side and two on the back of the
enclosure).
- Designed for a wide variety of sound
reinforcement applications including
permanent install (clubs) and portable live
sound.
- Tuned cabinet provides enhanced, low
distortion, high output performance.
- 18mm plywood construction.
Block Diagram
1+, 1-
UNU SED
LF/ HF
2+, 2-
HF 2+ ,2-
LF 1+ ,1-
500
1000
MX-115
Features
