MX-F18B Folded Horn Subwoofer
Subwoofer connections
Normal wiring connections from the
output of the low frequency amplifier
to the MX subwoofer are made via
NL4, Speakon
®
-type connectors
located on the rear mounted input
plate.
Connector pin wiring is configured as
follows:
1+ = Positive
1- = Negative
Block Diagram:
