Wharfedale Pro Pro PM600 - PM Series Mixer Specifications

MODEL PM500 MIXER PM600 MIXER
POWER AMP - MAX OUTPUT IN WATTS
4 OHMS 120 WATTS 230 WATTS
INPUTS
BALANCED MIC 4 5
LINE CHANNELS 5 6
INPUT IMPEDANCE
LOW Z (BALANCED) 2K/OHMS 2K/OHMS
LINE 16K/OHMS 16K/OHMS
MAIN OUT UNBAL. TRS UNBAL. TRS
FREQUENCY RESPONSE (+/-3dB) 20Hz to 25KHz 20Hz to 25KHz
MAXIMUM
CHANNEL
GAIN
LOW Z (BALANCED) 40dB 40dB
LINE 20dB 20dB
MAXIMUM
INPUT LEVEL
LOW Z (MIC) 0dB 0dB
LINE +20dB +20dB
MAXIMUM
OUTPUT LEVEL
MAIN +18dBv +18dBv
RECORD OUT +5dBv +5dBv
MASTER
EQ
HI EQ NA 12Khz±12DB
MID EQ NA 1Khz±12dB
LOW EQ NA 80Hz±12dB
CHANNEL
EQUALISATION
LOW EQ 80Hz ± 15dB 100Hz ± 12dB
HI EQ 12KHz±15dB 8KHz±12dB
PROTECTION THERMAL/LOAD THERMAL/LOAD
MASTER SECTION
BUILT IN DIGITAL EFFECT YES YES
THD LESS THAN 0.1% LESS THAN 0.1%
POWER CONSUMPTION 120 WATTS 230 WATTS
POWER REQUIREMENTS 160 WATTS 330 WATTS
SPEAKER CONNECTORS 1/4” JACK 1/4” JACK
WEIGHT
PM500 9.32KG/20.5lbs PM600 11.48KG/24.7lbs
PM500RM 7.6KG/16.7lbs PM600RM 9.72KG/21.4lbs
DIMENSIONS
PM500 475MM X 269MM X 155MM 18.7” x 10.5” x 6.1”
PM600 475MM X241MM X 188MM 18.7” x 9.5” x 7.4”
PM500RM 485MMX248MMX112MM 19” X 9.7” X 4.4”
PM600RM 485MMX228MMX145MM 19” X 8.9” X 5.7”
PM Series Instruction Manual Page 11
