WHEATON
®
Bench-Top Mini Bottle Roller Apparatus
11
WHEATON | 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | www.wheaton.com | P/N 50075499 Rev. 10/2014 WMAN_026
CONTROL BOARD REPLACEMENT (refer to fig. A - C)
DANGER! BE CERTAIN UNIT IS DISCONNECTED FROM THE AC POWER SOURCE.
1. Unplug the unit from power source.
2. Loosen the Allen screw, which secures the shaft extender (25) to the output shaft of motor (26).
Remove shaft extender assembly along with drive belts (8) and set aside.
3. Remove the four screws (underneath unit) which secure the cabinet lid to the cabinet base. Remove
lid.
4. Unplug the wire harness (24) from the control board (28).
5. Remove the four screws (9) that secure the control board to the cabinet base. Remove control board.
6. Unplug the harness connectors from the control board noting their location for proper replacement.
7. For re-assembly, reverse the above order using new control board.
