WHEATON
®
Bench-Top Mini Bottle Roller Apparatus
8
WHEATON | 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | www.wheaton.com | P/N 50075499 Rev. 10/2014 WMAN_026
GENERAL INFORMATION
This section contains a general description of the Wheaton Bench Top Mini Bottle Roller. This section
also contains instructions for initial inspection, installation, selecting the power-line voltage and
connecting the unit to AC power.
1. OPTIONS - WSP #348920-CH Mini Bottle Deck Kit (sold separately), can be added to accommodate
an additional (minimum of) four bottles per deck.
2. INITIAL INSPECTION - When you receive your Wheaton Bench Top Mini Bottle Roller, inspect it for
any obvious damage that may have occurred during shipment. If any damage is found, notify the
carrier at once. Warranty information is shown in the front of this manual. Check to confirm that there
are no broken switches, or pulleys and that the unit is not dented or scratched.
3. INSTALLATION - Install the unit where there will be adequate room for the unit to operate. Provide
enough clearance around the unit to keep items away from the rotating belts and pulleys.
4. INPUT POWER REQUIREMENTS - This equipment is designed to operate from a nominal 230V
single phase ac power source at 47 to 63 Hz. An indication on the rear of the unit shows the nominal
input voltage set for the unit at the factory.
5. POWER LINE CORD - This unit has been shipped from the factory with a power line cord that has a
plug appropriate for your area. If the wrong power cord has been shipped for your particular
application, contact your nearest Wheaton dealer for the proper cord. The Wheaton Bench Top Mini
Bottle Roller has been equipped with a 3-wire grounding type power cord. The unit is only grounded
when it is plugged into an appropriate receptacle. Do not operate the unit without adequate grounding
protection.
6. POWER LINE VOLTAGE SELECTION - Power line voltage selection is accomplished by adjusting
two components: the power line voltage selector and the power line fuse in the power line module on
the rear of the unit.
