Wheaton W348923-C - PARTS LIST

WHEATON
®
Bench-Top Mini Bottle Roller Apparatus
16
WHEATON | 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | www.wheaton.com | P/N 50075499 Rev. 10/2014 WMAN_026
WHEATON ROLLER APPARATUS #W348923-C, F & G - PARTS LIST (FIG. A-B)
ITEM NO. DESCRIPTION USE QTY. WHEATON NO.
1 FOOT, GRAY 4 50029504
2 RING, RETAINING 10 I051343
3 WASHER, #10 LOCK 2 I052338
4 KNOB, BLACK ABS, 1/8” SHAFT 1 I054954
5 VIBRATION ISOLATOR 4 I051499
6 FUSE, 0.25A, 250V, 5 X 20mm 2 50028423
7 POWER INPUT MODULE 1 50063467
8 BELT, TIMING 130XL187 2 I052172
9 SCREW, #6-32 X 1/4” LG., PPHM 4 I052239
10 SCREW, #4-40 X 3/8” LG., PFHM 2 I053401
11 SCREW, #6-32 X 3/8” LG., PPHM 8 I052240
12 SCREW, #8-32 X 1/4” LG., PPHM 4 I052287
13 WASHER, #8, STAR INT TOOTH 4 50029959
14 SCREW, #10-32 X 3/8” LG., PPHM 2 I052319
15 SET SCREW, #10-32 X 3/8” LG. 4 I052355
16 SCREW, #1/4-20 X 1/2” LG., PPHM 2 50027151
17 ROLLER, RUBBER 5 I053003
18 CABINET BASE 1 WI056104
19 CABINET LID 1 WI056106
20 ROLLER GEAR 2 I053004
21 STOP, NYLON 4 I053005
22 SHAFT, ROLLER 3 I053006
23 SHAFT, DRIVE 2 I053007
24 WIRE HARNESS 1 WI055434
25 SHAFT EXTENDER,1/4” 1 I053015
26 MOTOR, 24VDC, 65.5:1 12/24V 1 I057191
27 PULLEY, TIMING, 15XLB037 1 I053018
28 PCBA, CONTROL BOARD 1 I055017
29 NYLINER, #6L2FF 10 I051341
30 PLATE, MOTOR MTNG. 1 I054562
31 NUT, HEX, #6-32 5 50029919
32 WASHER, STAR, #6, INT. TOOTH 3 I052273
