Bench-Top Mini Bottle Roller Apparatus
15
WHEATON | 800.225.1437 (U.S. & Canada Only) | 856.825.1100 | www.wheaton.com | P/N 50075499 Rev. 10/2014 WMAN_026
WEEE DISMANTLING INSTRUCTIONS
This Small Bottle Bench-Top Roller apparatus is not to be discarded in typical trash outlets. This unit is to
be discarded according to WEEE guidelines established in your area. There are no reusable parts.
Contact the original distributor from which this product was purchased for proper disposal instructions.
Main Unit Disassembly
1. Refer to figure A. Remove belts from back of unit. Remove any cabling from back of unit. Remove
all pulleys from unit.
2. Remove any upper decks from unit (if provided), starting with the removal of the top deck and
working down to the bottom deck.
Control Housing Disassembly
1. Refer to figures A and B. Remove lid, belts, pulleys and cables from bottom of control housing
(Fig. A item 18).
2. Remove wire harness from unit. Remove control knob (Fig A. item 5).
3. Remove motor (Fig. A item 5) and motor controller (Fig A item 4).
4. Remove power entry module (Fig. A item 7).
5. Remove motor bracket and motor (Fig. A items 26 and 30)
6. Turn base control housing upside down and remove feet (Fig. A item 1).
Deck Disassembly
1. Refer to figure A. Remove pulleys (Item 20) and loosen roller spacers (Item 21).
2. Remove rubber rollers and shafts from deck.
3. The rubber sleeve can be removed from the aluminum roller shafts. This is a friction fit. No
adhesive is used to mount the rubber sleeve onto the shaft.
Materials Declaration
Chassis and control cabinet sheet metal
Aluminum with Sherwin Williams Polane
™
two-part
epoxy coating.
