P84333 K Sheet 8 of 23

.544"

1.060"

10.000"

13.950"

Figure 2:

Mounting Dimensions

DIMENSIONS (H x W x D) - 16” x 12.25” x 5”

NOTE: All dimensions shown are measured in inches.
