2-24
REMOVING THE TURNTABLE MOTOR
WARNING
Personal Injury Hazard
Disconnect from the electrical supply be-
fore servicing the unit. Failure to do so
could result in death or electrical shock.
3. Remove the base plate from the micro-
wave oven and unplug the cooktop light
connector (see the illustration on page
2-3).
4. Unplug the connector and remove the two
mounting screws from the turntable mo-
tor, then remove the motor from the bot-
tom of the microwave oven.
5. Mount the new turntable motor and reas-
semble the microwave oven.
1. Disconnect the electrical supply to the
microwave oven.
2. From inside the oven cavity, lift the turn-
table rest off the shaft of the turntable
motor
TURNTABLE
MOTOR
BOTTOM OF
OVEN
CONNECTOR
TURNTABLE REST
