Whirlpool 1997 "E" - Page 68

4-4
4. BLOWER MOTOR IS ON “HIGH”
5. OVEN IS OFF — CAVITY TEMPERATURE IS ABOVE 133˚F
BLOWER MOTOR IS ON “LOW”
6. COOKTOP LIGHTS ARE ON “HIGH” OR “LOW”
N
L1
20A LINE
FUSE
CAVITY
THERMAL
FUSE
MAGNETRON
THERMAL
FUSE
BK
BK
BK
RELAY 4
BASE
THERMAL
FUSE
W
BL
Y
Y
LOW-VOLTAGE
TRANSFORMER
W
BLOWER
MOTOR
RD
MICROCOMPUTER
BOARD
3 1
11
CAPACITOR
RD
(C)(HIGH)
N
L1
20A LINE
FUSE
CAVITY
THERMAL
FUSE
MAGNETRON
THERMAL
FUSE
BK
RD
BK
RELAY 4
W
BL
BK
LOW-VOLTAGE
TRANSFORMER
BLOWER MOTOR
RD
MICROCOMPUTER
BOARD
3 1
13
CAPACITOR
YRD
(HIGH) (C)
N
L1
20A LINE
FUSE
CAVITY
THERMAL
FUSE
MAGNETRON
THERMAL
FUSE
BK
BK
BK
BK
PH1
COOKTOP LIGHTS
W
W
LOW-VOLTAGE
TRANSFORMER
MICROCOMPUTER
BOARD
15
BL/BK
W
RD
3
1
