9
INSTALLATION INSTRUCTIONS
WARNING
Excessive Weight Hazard
Use two or more people to move and install or uninstall
appliance.
Failure to do so can result in back or other injury.
NOTE: To avoid floor damage, set machine onto cardboard before
moving it.
Move All-In-One Washer & Dryer
It is necessary to remove all shipping materials for proper
operation and to avoid excessive noise from machine.
Move machine to within 4 ft (1.2 m) of its final location. It must be
in a fully upright position.
Locate transport bolts
Locate four transport bolts on rear of machine.
Remove transport bolts from All-In-One Washer &
Dryer
Loosen bolts with a 5/8" (16 mm) wrench.
Remove each bolt from machine, by pulling in the direction of the
arrows, pull bolts and plastic spacers from back of machine.
Discard bolts and spacers.
NOTE: Do not plug machine in until installation has been
completed.
REQUIREMENTS
Tools and Parts
Tools needed:
Adjustable or open end
wrenches 1/2" (13 mm), 5/8"
(16 mm) and 9/16" (14 mm)
Level
Ruler or measuring tape Pliers that open to 1
9
/
16
"
(39.5 mm)
Optional tool
Flashlight Bucket
Parts needed (not supplied with machine):
Water inlet hoses (2) Flat inlet hose washers (4)
Parts supplied (not supplied with machine):
NOTE: All parts supplied for installation are in the machine
basket.
Cable tie Drain hose with clamp and
form (may be shipped
unassembled)
