SERVICE
07.11.2006 / Page 2 AWE 9725 Whirlpool Europe
Doc. No: 4812 722 26957 8593 972 10057 Customer Service
Technical data
Dimensions
Height 85 cm
Width 40 cm
Depth 60 cm
Weight
Net weight ~62 kg
With package ~64 kg
Main Connection
Voltage 230 V ± 10%
Frequency 50 Hz
Power consumption ~2.3 kW
Fuse rating 10 A
Drum
Door wide 210 mm
Volume 42 l
Wash spin 52 rpm
Speed spinning max. 1200 rpm
Capacity of dry laundry
Cotton 5 kg
Cotton short 3 kg
Easy care 2 kg
Daily mixed 3 kg
Super rapid 1.5 kg
Delicate 1.5 kg
Handwash 1 kg
Wool 1 kg
Pressostat
Kind of switch 2-level pressoswitch
with overflow contact
Type B1-117
Nominal voltage 230 V
Water Level
Foam level (11 - 12, 14)
Switching point 50 ± 5 mmWc
Switching back point 30 ± 5 mmWc
Overflow (21 - 26) 280 ± 20 mmWc
Nominal currents
Contacts
11 - 12 4 (4) mA
11 - 14 16 (4) A
11 - 16 1 (1) A
Door lock (5-pole)
Type BP P/5
Nominal voltage 230 (90 - 264) V
Nominal current:
Contact 4 - 5 16 (4) A
Lock time ≤5’’
Unlock time ≤180’’
Heating element
Kind of heating Tubular heating element
with NTC - sensor
Nominal voltage 230 +10%, -15% V
Nominal power 2050 W ± 5%
Resistance (20 ˚C) 23.9 Ω± 5%
Thermo-fuse (switch
OFF temperature) 152 ˚C
Leakage current (<99 ˚C) <0.8 mA
NTC sensor
Resistance NTC:
0 ˚C 35.9 kΩ ± 5.8%
30 ˚C 9.8 kΩ ± 3.7%
40 ˚C 6.6 kΩ ± 3.1%
50 ˚C 4.6 kΩ ± 2.6%
60 ˚C 3.2 kΩ ± 2.0%
70 ˚C 2.3 kΩ ± 2.5%
95 ˚C 1.1 kΩ ± 3.7%
Inlet valve
Kind of valve 1-way valve for cold
water
Water temperature <60 ˚C
Rated flow >1 bar 8 l/min ± 10%
Pressure range 0,2 - 10 bar
Nominal current 40 mA
Nominal power 8.8 VA ± 10%
Nominal resistance 3.8 kΩ± 10%
