SERVICE
07.11.2006 / Page 4 AWE 9725 Whirlpool Europe
Doc. No: 4812 722 26957 8593 972 10057 Customer Service
Spare part list
Model AWE 9725
Service No. 859397210057
Version 859397210057
Pos. No. 12NC Code Description
002 0 4812 459 38057 Flap round GW
002 1 4812 459 38058 Hinge flap GW
004 0 4812 440 10727 Drip tray assy
010 0 4812 459 48185 Door frame inner, soft opening GW
010 1 4812 440 10741 Frame lid outer MH/RFI GW
011 0 4812 462 48054 Foot
012 7 4812 310 18497 Trolley kit front
012 8 4812 528 78046 Foot adjustable rear
021 0 4812 440 10742 Front panel GW
022 0 4812 440 10743 Side panel right GW
022 1 4812 440 10744 Side panel left GW
024 0 4812 440 10732 Rear panel
040 0 4812 417 19155 Hinge bolt lid GW
061 0 4812 466 88466 Counter weight left
061 1 4812 466 88465 Counter weight right
081 4 4812 466 88699 Shock absorber
086 2 4812 401 18412 Stopper
086 4 4812 529 18045 Pin f. Shock absorber
086 5 4812 529 18052 Damper f. Shock absorber
100 1 4812 440 10745 Lid outer GW
100 3 4812 440 10746 Lid inner+hook+spring GW
100 5 4812 440 10747 Lid cpl. WH/MH GW
110 4 4812 498 18248 Handle cpl. WH/MH GW
130 0 4812 417 19156 Hook f. Lid GW
191 0 4812 466 68749 Door bellow
191 1 4812 492 98012 Strap f. Doorbellow
191 2 4812 466 88703 Seal
200 0 4812 418 18407 Tub f.Drum latch
201 0 4812 440 19487 Cover f. Tub
220 0 4812 418 18595 Drum soft op. 210mm
221 1 4812 310 18843 Kit latch f.drum
223 0 4819 418 49713 Drum lifter
223 1 4812 418 48605 Drum lifter 54 mm with weight
271 0 4812 358 18206 Belt PV 1236 J4 EL
272 0 4812 528 88111 Pulley with fastener
290 0 4812 532 68078 Gasket
301 0 4812 452 15491 Control panel AWE 9725
321 0 4812 452 15497 Insert panel
331 0 4812 412 59089 Knob timer EBL
332 0 4812 410 29015 Button Start GW
332 1 4812 410 29016 Button option with LED GW
332 2 4812 410 29017 Button option GW
332 5 4812 410 29243 Button temperature
332 6 4812 410 29244 Button spinning
350 1 4812 214 58334 Display Module 1400
400 0 4812 361 58387 Motor MCA 52/64-148 ALE
421 0 4812 121 18285 Interf.filter 1,00 µ F
421 2 4812 404 38708 Holder RFI
430 0 4812 360 18529 Pump,draining
451 0 4812 259 28919 Heating element 2050W, 230V + NTC
490 0 4819 321 18136 Cable mains 2m SA
490 1 4812 321 28367 Strain relief
521 0 4812 214 79589 Control board OMEGA, programmed
521 1 4812 323 18006 Actuator f. Distribution
571 0 4812 281 28393 Valve magnet
Pos. No. 12NC Code Description
571 1 4812 281 18049 Cover f. valve
581 0 4812 271 28382 Pressostat single EATON
623 3 4812 418 18446 Drum up OMEGA
630 0 4812 271 38364 Door lock
691 0 4812 282 19485 Sensor NTC SC1,OMEGA3
701 0 4812 530 29329 Hose inlet EN 11770 Reflex
702 2 4812 530 28871 Hose VALVE-DISPENSER
707 0 4812 526 48122 Nozzle box cold cpl.
707 1 4812 526 48049 Clamp f. nozzle box
712 4 4812 418 68302 Siphon f. softener
712 5 4812 418 68303 Siphon f. bleach
712 6 4812 418 68164 Clip SOAP DISPENSER
712 9 4812 418 68359 Soap dispenser cpl. 4 ch.
717 6 4812 323 18005 Distributor System
753 0 4812 530 28874 Chamber,air
754 0 4812 530 29267 Drainhose
754 1 4812 530 28832 Lock eco
760 0 4812 480 58089 Filter set pump
781 0 4819 530 29035 Hose draining
782 0 4812 530 29268 Hose Pressostat
787 0 4812 530 18043 Hose Exhaust W/O hole
787 1 4812 580 38007 Sponge
794 0 4812 530 58098 Gasket Airtrap
900 0 4819 401 18686 Clamp hose
900 1 4812 401 18431 Clamp to pump
900 2 4812 404 38711 Holder Hose
900 3 4819 401 18529 Clamp hose
900 6 4812 400 18048 Pin
900 7 4812 401 18447 Clamp top frame
901 0 4812 401 18462 Clamp hose drain hose
910 0 4812 502 48347 Screw,selftap 3,5x14SS
910 1 4812 502 38151 Screw 4x14
910 3 4812 502 18404 Screw
910 4 4812 502 18402 Screw 7x18
910 5 4812 502 18401 Screw M8X 35
910 6 4812 502 18399 Nut Push in M 8
921 0 4812 400 18047 Washer
930 1 4812 492 48171 Torsions spring
930 2 4812 492 48086 Spring
930 3 4812 323 18011 Spring f. Lever
941 1 4812 520 28002 Bearing,ball 6203 2Z C3
941 2 4812 520 28182 Bearing,ball kit
953 0 4812 325 68001 Shaft seal
953 1 4812 520 28073 Ring counterface
953 2 4812 530 68017 O-Ring
962 0 4812 440 19497 Cover f. Motor
993 0 4819 530 29028 Bow
993 1 4812 290 18031 Clamp heatingelement+screw
