WHIRLPOOL CONSUMER SERVICES
Model AWM8121
Page 5 of 22
TECHNICAL DATA (Cont.)
Program timer
Type SC1
Timer basic 4619 712 52201
Timer programmed 4619 744 80153
Nominal voltage 230 - .240 V
Frequency 50 Hz
Harness Connectors (See circuit
diagram)
OA4.1 - OA4.2 5. Option
OA4.3 - OA4.4 6. Option
OB4.1 - OB4.2 3. Option
OB4.3 - OB4.4 4. Option
OC4.1 - OC4.2 1. Option
OC4.3 - OC4.4 2. Option
SLT3.1 - SLT3.3 Temp.selector
SLS4.1 - SLS4.4 Spin speed selector
VCF3.1 - VCF3.3 Valve (cold water)
VHF3.1 - VHF3.3 Valve (hot water)
Pi5.1 = negative supply
Pi5.2 = data
Pi5.3 = clock
Pi5.4 = positive supply
Pi 5.5 = negative supply
PL3.1 - PL3.3 Pilot lamp
Connector
M7.1 - M7.7 Motor
DP2.1 - DP2.2 Pump
SET2.1 - SET2.2 NTC
DSS3.1 - DSS3.3 Door switch
PR2.1 - PR2.2 Pressostat
Single connector
HE2.1 - HE2.2 Heating element
PS2.1 - PS2.2 Pressostat
SM3.2 - SM3.3 Mains switch (3 fold
connector)
Program 32 positions
Step Cotton
/
Colour
Easy
care
Deli-
cate
Wool Silk
Pre
wash
02-06 03-06 04-06 - -
Main
wash
07-21 12-21 14-21 17-21 18-21
Rinse 22-28 22-28 22-28 22-28 22-28
Spin 29-31 29-31 29-31 29-31 29-31
Stop 32 32 32 32 32
Speeds
Wash speed 54 rpm
Ramp speed 95 rpm
Spin speed 1200 rpm
Ambient Temperatures
Ambient temperature up to 70 °C
Storage temperature up to 85 °C
Output
Motor M7.6 - DSS 3.2 >40 V
in pump step AQ2.1 -DSS 3.2 240 V
NTC not measurable
Pump DP2.1 -DP2.2 240 V
Doorlock DSS3.1 -DSS 3.3 240 V
Pressostat E4 - E2 240 V
- empty PR2.1 - E2 240 V
- full PR2.2 - E2 240 V
Valve (Rast 2,5) V2.1 - V2.2 >170 V
Options not measurable
Display module Pi5.1 - Pi5. 4.5 V
Pi5.4 - Pi5.5 12 V
Motor
Type MCA61/64 - 148 t.f.
WHE 0
Belt ratio i = 1 : 13.3
Resistance contacts
6 - 7 68.7± 7% Ω
4 - 5 1.78± 7% Ω
2 - 3 1.68± 7% Ω
1 - 3 0.99± 7% Ω
