Press " Rinse " button
Protocol version
information
d indicates that the communication protocol version
number is displayed alternately(For example, D02
201 indicates that the display protocol version is 01
and the main control protocol version is 201.)
Press " Rinse " button
Water level information
Indicates water level frequency (hexadecimal)
(double light when water level is greater than 3
levels)
Press " Rinse " button
Temperature information
H XX indicate the drying air duct temperature
XX Indicates water heating temperature
Press " Rinse " button
00
Ready to enter the automatic load detection state
The water level sensor adopted in the detection platform is the model 61-C, the empty level parameter between 2968 - 2A62.
The illumination of the door lock word light shows that the door lock is at closed state. turns / minutes Flashing shows 3D abnormal
In the test mode and the Electrical Components Inspection mode, press the "Wash" button to select the test item. Press the "Start / Pause" button
to execute the current selected action. Press it again to stop the current action. The Detergent flashing shows that the test is being performed.
The electrical components check takes 10 minutes at most. After 10 minutes, the check action stops. The door lock indicator light shows the
state of the door lock switch.Door lock indicator light is on when the door lock switch is closed.
Correspondence relationship between each electrical component & program indicator light and the washing time value:
Program Set
No
Electrical component action（combo）
Electrical component action
（washer）
Mixed
00 Main Water Main Water
01 sterilizing liquid enters water sterilizing liquid enters water
02 Dehumidification inlet water
03 Main Water + sterilizing liquid enters water
+ Dehumidification inlet water
（Softener inlet water + Dehumidification
inlet water）
Main Water + sterilizing liquid
enters water （Softener inlet
water）
04 Water heating tube 5 seconds ON Water heating tube 5 seconds ON
05 Drying the heating tube for 5 seconds ON
06
07
Quick
/Wash&
dry60’
00 Water heating tube 5 seconds ON Water heating tube 5 seconds ON
01 Drying the heating tube for 5 seconds ON
02 Fan
03 Forced spin Forced spin
04
05
Gentle
00 Fan
01 Forced spin Forced spin
* Compulsive spinning final speed is set to 900 RPM.
