40
12. Rear cover
A Remove the 6 fastening screws
shown in the picture and remove the
back cover.
13. Motor
Remove the 2 screws and belt screws
fixing the motor. Unplug all the
harness connectors. Cut off the tie to
remove the motor (the drive plate
box is connected with the motor)
BPry
open the four buckles around the
main control board box to open the
box body
卡扣向右后方推
