©Service Competence Center
Components
Overview Components For Induction Plug
Induction Oven
Female plug inside the cavity.
The 2 metal bolts are never connected to the
power and support the guiding of the shelf into
the correct position.
The contacts of the female plug are only
energized when the induction shelf module is
correctly connected. In case the induction
function is selected and the induction shelf
module has not correctly positioned an
information on the display will be given. The
power control is managed by the electronic
without using an additional switch. This is
realized by periodically checking of the
resistance of the NTC in the induction shelf
module.
For cleaning use a humid sponge. Do not use
metallic and/or sharp tools.
1
1
2
2
Rear view to female plug and cable connection.
