Components
Lamp
Induction Oven
Lamp behaviour is managed by Navigator through a bit sent to the Control Board to turns
ON/OFF the lamp such as following specify:
Lamp ON:
• Door Open
• Cooking (If cooking function request lamp ON)
• Meat Probe inserted and detected (MP board is powered by lamp relay)
• End of pre-heat of cooking function (if ECO mode is enabled)
• Power ON of system
• Interaction of user with door opened (in case of the lamp is OFF).
• -by‟) if
meat probe was inserted before the switching OFF.
• Functional knob is in lamp position (for rotary model).
