7
Run water for a few seconds through hoses into a laundry
tub, drainpipe, or bucket to avoid clogs. Water should run
until clear.
12. Clear water lines
11. Connect inlet hoses to water
faucets
For oor drain installations, you will need to remove the drain
hose form from the end of the drain hose. You may need
additional parts with separate directions. See “Alternate Parts”.
8. Remove drain hose form
(oor drain installations only)
Place hose into standpipe (shown in picture) or over side of
laundry tub.
IMPORTANT: Only 4.5" (114 mm) of drain hose should be
inside standpipe; do not force excess hose into standpipe or
lay on bottom of laundry tub. Drain hose form must be used.
9. Place drain hose in standpipe
4.5"
(114 mm)
Drain
hose form
CONNECT INLET HOSES
IMPORTANT: To avoid leaks, check that your water inlet
hoses have at washers at both ends. Washer must be
connected to water faucets with new inlet hoses with at
washers (not provided). Do not use old hoses. Do not use
hoses without washers.
Attach the hose labeled hot to hot water faucet. Screw
on coupling by hand until it is seated on washer. Use pliers
to tighten couplings an additional two-thirds turn. Repeat
this step with the hose labeled cold for the cold water faucet.
Both hoses must be connected for washer to work properly.
IMPORTANT: Do not overtighten or use tape or sealants on
valve when attaching to faucets or washer. Damage can result.
HELPFUL TIP: Make note of which hose is connected to hot
water to help in attaching hoses to washer correctly. In most
standard congurations, hoses will cross over each other
when attached correctly.
Insert new at washers
10.
A. Coupling B. Washer
