MODELS: WW JB 629 –13 A & WW JB 629 –H3A
Course select
The combination of wash, agitronic soak, wash and rinse operations in a logical
fashion are selected by pressing this button. The process selected with the number of
presses of the button is as in the table below
Option button Process selected
Power switch on (Auto setting)
Wash Rinse Spin
Press once
Agitronic
soak
Wash Rinse Spin
Press twice
Wash
Press thrice
wash Rinse
Press fourth time
Rinse Spin
Press fifth time
Spin
• Agitronic soak is a unique option available in white magic, which will enhance the
wash performance.
• Wash only option can be used as a water saver feature for two wash loads.
• Wash, rinse option can be used if customer does not prefer spin dry clothes.
• Rinse, spin option can be used if the customer opted for wash only option at the
beginning of water saver operation.
Start/Pause button
This button is used to start or pause the cycle. Once all the settings are made using
the program and course select buttons the user has to press Start/Pause button to start the
chosen cycle. The operation can be paused in the middle of the cycle by pressing the
Start/Pause button and pressing the button again will continue the cycle. The customer for
adding more detergent or clothes in the middle of the cycle can use this option.
Cancel button
This feature enables the user to cancel all the settings made earlier at the
commencement of the cycle and return to default settings i.e. normal cycle with wash
rinse and spin option.
LED indicators
This is two sets of four LED’s each, which are provided in the control panel. This
indicates the status of the cycle in progress.
Wash programs
