Whirlpool of India
WHITE MAGIC
MODELS: WW JB 629 –13 A & WW JB 629 –H3A
Sl_No Sap No. Description 1120 1121
1
P012531020A WATER INLET VALVE (TM) 1 1
2
P014354010C PCB ASSY. ALAVINCI - ALPHA 1 1
3
P014341010A WIRING HARNESS (L) - ALA ALPHA 1 1
4
P014341070B WIRING HARNESS (R) - ALA ALPHA 1 1
5
S017600210A TOROID COIL MODULE 1 1
*
P010142030C CLIP - CONTROL KNOB 1 1
*
P0143600500 DAMPER LID - WHITEMAGIC 1 1
*
P014330030A HINGE PIN - WHITEMAGIC 2 2
*
P0143301200 HINGE SPRING W/M 2 2
*
P014330710A HOLDER - LID SWITCH - ALAVINCI 1 1
*
P0143310200 HOSE - COLD VALVE (ALAVINCI) 1 1
*
P014330660B LID SWITCH - ALAVINCI 1 1
*
P014353020A PCB SPACER - BIG - WHITEMAGIC 1 1
*
P014353010A PCB SPACER -SMALL - WHITEMAGIC 1 1
*
S017100000A PIG TAIL CONNECTOR-3 DIA 1 1
*
P013840310A POWER CORD - MEXICO 1 1
*
P012941010H PRESSURE SWITCH (A) 1 1
*
P014341030B PROTECTOR 1 1
TOP ASSEMBLY
SAP M ODEL NO.
#
* Not Shown
#
SAP MODEL NUMBER
1120 WHITEMAGIC - AWD6800 - GREY
1121 WHITEMAGIC - AWD6800 - WHITE
This document is only intended for qualified technicians who are aware of the respective safety regulations.
Releaded Date 27
h
Feb, 2001 Subject to modification
Document No. WOI/WM/2001/001
PAGE 23 of 44
