Whirlpool White Magic - Page 27

Whirlpool of India
WHITE MAGIC
MODELS: WW JB 629 –13 A & WW JB 629 –H3A
Sl_No Sap No. Description 1120 1121
1
P0143150400 BLUE DISPENSER ASSY. - WM -WHITE 1 1
2
P0143100200 DUAL ACTION AGITATOR SUB ASSY. 1 1
3
P014313010B BASKET ASSY. COMP. (DOUB. WALL) 1 1
4
P012913020A DRIVE HUB - MACHINED (PL. BASKET) 1 1
5
P010113110B SADDLE BLOCK 1 1
6
S011280480B SCREW - M6 X 28 HEX HD - SS 6 6
7
P0101130600 BALANCE RING ASSY. (COGY) 1 1
*
P014313060B MAGIC LINT FILTER - ALAVINCI 6 6
*
P012513030D RING BOTTOM - COGY 1 1
BASKET AND AGITATOR ASSEMBLY
SAP M ODEL NO.
#
* Not Shown
#
SAP MODEL NUMBER
1120 WHITEMAGIC - AWD6800 - GREY
1121 WHITEMAGIC - AWD6800 - WHITE
This document is only intended for qualified technicians who are aware of the respective safety regulations.
Releaded Date 27
h
Feb, 2001 Subject to modification
Document No. WOI/WM/2001/001
PAGE 27 of 44
