Whirlpool White Magic - Page 29

Whirlpool of India
WHITE MAGIC
MODELS: WW JB 629 –13 A & WW JB 629 –H3A
Sl_No Sap No. Description 1120 1121
1
P010112000C TUB ASSY. 1 1
2
P010110100A HOSE-TUB OVER FLOW 1 1
3
P0152100100 HOSE - TUB TO DV ( HEATER) 1 1
4
P0129110100 DRIVE ASSY. - A/S 1 1
5
S014010050B CLAMP-39 DIA. 1 1
6
P010111500C BRACKET-CAPACITOR 1 1
7
S014010010A CLAMP-33 DIA. 1 1
8
P0101110100 TUB SUPP. BRG & SEAL ASSY 1 1
9
P012910020E TUB RING (A/S) - COGY 1 1
10
P011111060A MOTOR PLATE ASSY - RWH 1 1
11
P010111070E SLIDER-SPLUTCH 1 1
12
P010111400A CAM RING-SPLUTCH 1 1
13
P010111520B CAM-SPLUTCH 1 1
14
S013800T001-0 SNAP RING 1 1
15
P010111390A SPRING - SPLUTCH (CONICAL) 1 1
16
P011210010B HOSE-L.BEND TO TCC(R&R) D:36,L:200 1 1
17
P014311000A TORQUE MOTOR 1 1
18
S016150030C CAPACITOR-INDUCTANCE CAN 1 1
19
S014010100A CLAMP - ID 13.9/13.3 1 1
20 P014330670A HOSE - BLEACH 1 1
21
P014330680B HOSE - PRESSURE SWITCH (ALAVINCI) 1 1
22
P010111140B BRAKE & ARM ASSY. 1 1
TUB AND TUB SUPPORT ASSEMBLY
SAP M ODEL NO.
#
#
SAP MODEL NUMBER
1120 WHITEMAGIC - AWD6800 - GREY
1121 WHITEMAGIC - AWD6800 - WHITE
This document is only intended for qualified technicians who are aware of the respective safety regulations.
Releaded Date 27
h
Feb, 2001 Subject to modification
Document No. WOI/WM/2001/001
PAGE 29 of 44
