Whirlpool White Magic - Page 38

Whirlpool of India
WHITE MAGIC
MODELS: WW JB 629 –13 A & WW JB 629 –H3A
YES
YES
YES
YES
YES
YES
YES
This document is only intended for qualified technicians who are aware of the respective safety regulations.
Releaded Date 27
h
Feb, 2001 Subject to modification
Document No. WOI/WM/2001/001
PAGE 38 of 44
Defective wiring
harness?
Replace wiring
harness
Defective Capacitor Replace capacitor
Defective Motor
Replace Motor
Assembly
Leaky dump valve
Arrest the leak
Drive belt cut?
Replace drive belt
Defective Splutch
Assy.?
Replace Splutch Assy.
Defective drive
Assy.
Replace Drive Assy.
NO
NO
NO
NO
NO
NO
NO
