Whirlpool of India
WHITE MAGIC
MODELS: WW JB 629 –13 A & WW JB 629 –H3A
2.1 Model description : White Magic.
2.2 Dimensions : Unpacked 570 mm (W) x 585 mm (D) x 1020mm (H) 38 Kg.
Packed 615 mm (W) x 623 mm (D) x 1037mm (H) 44 Kg.
2.3 Console construction : One piece top with control base housing all controls. The
graphics and switch operating dome provided on escutcheon.
2.4 Top Opening : Access with lid with center transparent window.
2.5 Cabinet finish : Pre painted steel.
2.6 Timer type : Microprocessor controlled.
2.7 Number of programs : 19
2.8 Programs select : 4 LED's Normal, Speedy, Heavy & Delicate
(Double rinse in Heavy)
2.9 Status/Pause : Provided.
2.10 Cancel : Provided.
2.11 Error Signal (audio) : 3 distinct for lid open, power resumption and drain hose
block.
2.12 Wash action : Auto select depending on program selected through
option selected (Agitronic soak, Wash, Rinse and Spin).
2.13 Program retention : Holds 24 Hours.
2.14 Dispenser : Detergent dispenser (90-g capacity).
Bleach dispenser - hose type.
Blue dispensing (Through dispenser fitted to Agitator).
Softener dispensing (Through dispenser fitted to Agitator).
2.15 Lint filter : Available (Fitted to basket). It is self cleaning.
2.16 Motor : 1/4 HP 1760 +/- 20 RPM, PSC type single speed.
reversible
2.17 Operating Voltage : 220V @ 60 Hz.
This document is only intended for qualified technicians who are aware of the respective safety regulations.
Releaded Date 27
h
Feb, 2001 Subject to modification
Document No. WOI/WM/2001/001
PAGE 6 of 44
