White 656 - Bobbin Handling and Winding; Removing the Bobbin Case; Replacing the Bobbin Case; Winding the Bobbin

8
Removing
Bobbin
Case
From
Machine
-
Lift
hinged
plate
at
left
end
of
machine
bed-
plate.
Look
down
and
slightly
right:
You
will
see
the
assembly
pictured
(right).
With
fingernail
of
left
hand
first
finger
under
rear
edge
of
latch
D,pull
straight
out
and use
raised
latch
as
finger
grip
to
remove
bobbin
case
containing
bobbin.
—
To
Replace
Bobbin
Case
in
Machine
Reverse
above
procedure.
When
sliding
case
onto
shuttle
center
stud
C
be
sure that
threaded
finger
(E)
is
directly
upright
so
it
will
enter
shuttle
race notch
A)
as
you
push
case
B
into
Sewing
position,
finally
releasing
latch
D)
to
hold
it.
—
Winding
Refilling
A
Bobbin
Place a
spool
of
thread
on
one
of
th€
spool
pins,
lead
thread
through
the
upper
thread
guides
on
the
arm, and
down
through
the
tension
disc
T
at
the base of
the
machine.
Run
end of
thread
through
a
hole
in
the
bobbin
edge
and place
bobbin
on
spindle
S
of
bobbin
winder,
fitting
the
notch
on
bobbin
over
small pin
on
spindle.
Push
bobbin
winder
pulley
P)
against
hand
wheel
which
will declutch
the sewing
mechanism.
Hold
thread
end
loosely
and
start machine
slowly.
Bobbin
will stop
winding
when
it
is
filled.
By
moving
the
bobbin
winder
from
the hand wheel
it
will
engage
the
sewing
mechanism.
Approximate
one
turn
of
the
hand
wheel
may
be
required
to
completely
engage
sewing
mechanism.
