Whyte 29 CS - Page 6

2016 Edition 1
Page 6
WHYTE Service Manual
2.2.2: WHYTE 405
Frame Size X
Small Medium Large
Extra
Large
Head Angle
A
68.5° 68.5° 68.5° 68.5°
Seat Angle
B
73.0° 73.0° 73.0° 73.0°
Top Tube
C
580.5mm 594.5mm 612.4mm 632.2mm
BB Height*
D
305mm 305mm 305mm 305mm
Stand Over
E
800mm 810mm 836mm 850mm
Wheel Base
F
1123mm 1138mm 1158mm 1178mm
Chain Stay
G
440mm 440mm 440mm 440mm
Seat Post
H
30.9mm 30.9mm 30.9mm 30.9mm
2.2.3: WHYTE 529 & 629
Note:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø738mm tyres fitted (2.1” / 52-622)
Frame Size X
13”
Head Angle
A
68.5°
Seat Angle
B
74.0°
Top Tube
C
629.4mm
BB Height*
D
305mm
Stand Over
E
711mm
Wheel Base
F
1068.6mm
Chain Stay
G
425mm
Seat Post
H
30.9mm
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø677mm tyres fitted (2.25” / 54-559)
