Whyte 29 CS - Page 7

2016 Edition 1
Page 7
Frame Size X
Small Medium Large Extra Large
Head Angle
A
68.5° 68.5° 68.5° 68.5°
Seat Angle
B
73.5° 73.5° 73.0° 73.0°
Top Tube
C
593.5mm 608.1m 627.9mm 638.8mm
BB Height*
D
303.5mm 303.5mm 303.5mm 303.5mm
Stand Over
E
779mm 797mm 822mm 851mm
Wheel Base
F
1107.1mm 1122.6mm 1137.4mm 1149.1mm
Chain Stay
G
435mm 435mm 435mm 435mm
Seat Post
H
30.9mm 30.9mm 30.9mm 30.9mm
2.2.4: WHYTE 603, 605, 801 & 805
Note:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø717mm tyres fitted (2.25” / 52-584).
WHYTE Service Manual
Frame Size X
Small Medium
Head Angle
A
68.5° 68.5°
Seat Angle
B
73.5° 73.5°
Top Tube
C
585.5mm 599.6m
BB Height*
D
303.5mm 303.5mm
Stand Over
E
784mm 804mm
Wheel Base
F
1099.1mm 1114.1mm
Chain Stay
G
435mm 435mm
Seat Post
H
30.9mm 30.9mm
Extra Small
68.5°
74.0°
570.6mm
303.5mm
776mm
1089.1mm
435mm
30.9mm
Large
68.5°
73.5°
613.7mm
303.5mm
829mm
1129.1mm
435mm
30.9mm
2.2.5: WHYTE 604, 802 & 806
Note:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø717mm tyres fitted (2.25” / 52-584).
