Whyte 29 CS - Page 8

2016 Edition 1
Page 8
WHYTE Service Manual
Frame Size
Small Medium Large
Head Angle 66.5° 66.5° 66.5°
Seat Angle 73.0° 73.0° 73.0°
Top Tube 619mm 638mm 655mm
BB Height* 305.0mm 305.0mm 305.0mm
Stand Over 778mm 794mm 816mm
Wheel Base 1139mm 1169mm 1178mm
Chain Stay 425mm 425mm 425mm
Seat Post 30.9mm 30.9mm 30.9mm
X
A
B
C
D
E
F
G
H
Extra Large
66.5°
73.0°
674mm
305.0mm
833mm
1204mm
430mm
30.9mm
2.2.6: WHYTE 901
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø717mm tyres fitted (2.25” / 54-584)
Frame Size
Small Medium Large
Head Angle 66.5° 66.5° 66.5°
Seat Angle 73.0° 73.0° 73.0°
Top Tube 619mm 638mm 655mm
BB Height* 305.0mm 305.0mm 305.0mm
Stand Over 770mm 805mm 832mm
Wheel Base 1139mm 1169mm 1178mm
Chain Stay 425mm 425mm 425mm
Seat Post 30.9mm 30.9mm 30.9mm
X
A
B
C
D
E
F
G
H
Extra Large
66.5°
73.0°
674mm
305.0mm
861mm
1204mm
430mm
30.9mm
2.2.7: WHYTE 905 & 909
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø717mm tyres fitted (2.25” / 54-584)
