Fig. 1 & 2: Table of Components
Fig 3: Table of Components
Item Description
1 Main Frame
2 Chain Stays
3 Seat Stays
4 Link
5 Shape-It Link
6 Rear Shock Absorber
7 M6 Socket Head Cap Screw
8 8mm Hollow Pivot Pin 31mm Long
9 Collar for M5 Screws
10 M5 x 16 Socket Head Cap Screws T25 Torx
11 Pivot Pin 80mm Long
12 Tapered Sleeve for Expanding Collet
13 M6 x 20 Long Socket Head Cap Screw
14 M15 Pivot Screw 28mm Long
15 M15 Pivot Screw 28mm Long
16 M15 Pivot Screw 18mm Long
17 M15 Pivot Screw 28mm Long
Item Description
10 M6 x 20 long Capscrew (5mm A/F Internal Hex)
11 Tapered Sleeve for Expanding Collet
12 Pivot Pin 80mm long, expanding collet, M15 thread.
14 Chain-stays
15 Main Frame
19 Shield Washer (O.D. 23mm)
20 Bearing: 3802V2RD (MN) KR-BOLU
21 Internal Spacer (49mm long)
