WHYTE Mudguard Assembly Instructions
Terminology
1. Front Fork Crown & Thickness.
2. Disc Brake Caliper.
3. Seat-stay.
4. Chain-stay.
5. Rear drop-out.
6. Seat-stay bridge.
7. Stepped seat-stay bridge hole.
8. Chain-stay bridge.
9. Threaded chain-stay bridge hole.
Side Stay Lengths:
300mm long for 46mm wide mudguards.
315mm long for 38mm wide mudguards.
1
1
2
7
6
8
9
3
4
5
