WHYTE Mudguard Assembly Instructions
Mounting Hardware:
38mm Wide Mudguards
Description Reference Quantity
Button head cap-screw M5 x 25 long 26 1
Button head cap-screw M6 x 12 long 12 1
Button head cap-screw M6 x 30 long 16 1
Button head cap-screw M6 x 50 long 8 1
Button head cap-screw M6 x 60 long 8 1
Cap-screw M5 x 12 long 6 3
Cap-screw M5 x 16 long 21 4
Cap-screw M5 x 20 long 22 1
Cap-screw M6 x 65 long 8 1
Cycle brake nut M6 thread x 10mm long 18 1
Nut M6 Nylock 10 2
Spacer Ø6.2 hole x Ø15 outside x 5 long 23 2
Spacer Ø5.2 hole x Ø10 outside x 10 long 25 1
Washer Ø5 hole x Ø13 outside x 0.8 thick 7 13
Washer Ø6 hole x Ø12 outside x 1.6 thick 9 3
Washer Ø6 hole x Ø18 outside x 1.6 thick 17 1
Button head cap-screw M5 x 35 long 24 1
46mm Wide Mudguards
Description Reference Quantity
Button head cap-screw M6 x 12 long 12 2
Button head cap-screw M6 x 35 long 19 1
Cap-screw M5 x 12 long 6 2
Cap-screw M5 x 16 long 21 2
Cycle brake nut M6 thread x 10mm long 18 1
Nut M6 Nylock 10 2
Spacer Ø6.2 hole x Ø15 outside x 5 thick 23 1
Washer Ø5 hole x Ø13 outside x 0.8 thick 7 4
Washer Ø6 hole x Ø12 outside x 1.6 thick 9 3
Washer Ø6 hole x Ø18 outside x 1.6 thick 17 1
