Whyte T-129 S - Page 34

Page 34
2016 Edition 1
WHYTE Service Manual
Figure 22: Whyte Dropout Assembly -
For Shimano E-Thru
Item Description
1 M4 x 16mm long Hex Head Cap Screw
2 Adjustment Clamp
3 Rear Derailleur Hanger, for Shimano E-Thru (Grey Colour)
5 Seat Stay, Right Side
4 Axle Nut, for Shimano E-Thru
