Page 6
2016 Edition 1
WHYTE Service Manual
Frame Size X Small Medium Large
Head Angle A 65.5° 65.5° 65.5°
Seat Angle* B 74.7° 74.5° 74.3°
Top Tube C 607.6mm 636.6mm 655.9mm
BB Height** D 342.5mm 342.5mm 342.5mm
Stand Over E 808mm 816mm 822mm
Wheel Base F 1181.7mm 1211.7mm 1231.7mm
Chain Stay G 425mm 425mm 425mm
Seat Post H 30.9mm 30.9mm 30.9mm
2.1: Whyte G-160 Geometry
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at front and rear. Please refer to suspension set up for information on how to achieve the correct sag of the
fork and rear damper.
* Effective seat angle, from wheel centres horizontal to line from BB to seat post axis @ top of saddle.
** BB height with Ø717mm tyres fitted (2.25” / 54-584)
Frame Size X Small Medium Extra-Large
Head Angle A 66.5° 66.5° 66.5°
Seat Angle* B 73.7° 73.5° 73.2°
Top Tube C 591.4mm 611.1mm 650.7mm
BB Height** D 331.0mm 331.0mm 331.0mm
Stand Over E 763mm 766mm 776mm
Wheel Base F 1136.5mm 1156.5mm 1196.5mm
Chain Stay G 420mm 420mm 420mm
Seat Post H 30.9mm 30.9mm 30.9mm
Extra Small
66.5°
74.0°
571.7mm
331.0mm
761mm
1118.5mm
420mm
30.9mm
Large
66.5°
73.3°
631.0mm
331.0mm
776mm
1176.5mm
420mm
30.9mm
2.2: Whyte T-130-C & T-130 Geometry
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at front and rear. Please refer to suspension set up for information on how to achieve the correct sag of the
fork and rear damper.
* Effective seat angle, from wheel centres horizontal to line from BB to seat post axis @ top of saddle.
** BB height with Ø717mm tyres fitted (2.25” / 54-584)
