Page 7 2016 Edition 1
2.3: Whyte T-129 Geometry
WHYTE Service Manual
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at front and rear. Please refer to suspension set up for information on how to achieve the correct sag of the
fork and rear damper.
* Effective seat angle, from wheel centres horizontal to line from BB to seat post axis @ top of saddle.
** BB height with Ø748mm tyres fitted (29” x 2.25” / 54/56-622)
Frame Size X Small Medium Large
Head Angle A 66.5° 66.5° 66.5°
Seat Angle* B 74.2° 74.0° 73.8°
Top Tube C 593.4mm 613.4mm 633.1mm
BB Height** D 335mm 335mm 335mm
Stand Over E 800mm 805mm 810mm
Wheel Base F 1156.1mm 1176.1mm 1196.1mm
Chain Stay G 431mm 431mm 431mm
Seat Post H 30.9mm 30.9mm 30.9mm
Extra—Large
66.5°
73.6°
652.8mm
335mm
815mm
1216.1mm
431mm
30.9mm
