ASSEMBLY GUIDE
Please check to ensure you have all of the
components of your sharpener. You
should have each of the items listed here
in the quantity shown in parentheses.
1. Knife Sharpener Base (1)
2. Fixed Vise Jaw (1)
3. Free Vise Jaw (1)
4.
L-bracket, Ball Joint and Guide Rod Assembly (2)
5. Depth Key (1)
6. Vise Key (1)
7. Degree Bar (1)
8. Alignment Guide (1)
9. Knife Brace (1)
10. Upper Vise Screw - 5/8” Flat Head Screw (1)
11. Lower Vise Screw - 3/4” Flat Head Screw (1)
12. 1/2” Socket Head Cap Screw (1)
13. 1” Socket Head Cap Screw (1)
14. 1 1/2” Flat Head Cap Screw (2)
15. Thumb Screws (2)
16. Red Coarse 100 and Orange Medium 200 Grit
Diamond Stones (2)
17. Yellow Medium 400 and Green Fine 600 Grit
Diamond Stones (2)
18. Extra Upper Vise Screw - 1/2” Flat Head Screw (1)
3
2
5
7
8
9
44
15
15
16
17
6
1
18 • assembly guide • wickededgeusa.com
14
13
12
11
1018
Fig. 10
