Widinovations Widlaser C500 - 3.4. Machine characteristics

widinovations Confidential ©
13|41
V3.3
3.4. Machine characteristics
3.4.1. Physical dimensions
The widlaser C500, external measures are, 1.200 x 1.000 x 1.120mm (W x L x H).
The machine installation foot print is 2.400 x 1.600mm. This includes the minimum free area of 600mm, around
the equipment.
The minimum height clearance for the installation is 1.650mm.
