Widinovations Widlaser C500 - Page 19

widinovations Confidential ©
19|41
V3.3
1. WATER CHILLER UNIT *
Power input
AC 230v AC ± 5%, 50/60Hz
Maximum lift
10m
Pump volume
15L/min
Rated current
2.5A
Cooling agent
R134a
Colling agent amount
220g
*In the case of the air-cooled laser the chiller unit is not installed.
EXHAUST UNIT
Power input
AC 230v AC ± 5%, 50/60Hz
Rated current
1.52 A
Power consumption
330w
Speed
2800 rpm
Air flow
11m
3
/min
Air pressure
450 pa
Connection diameter
150 mm
